● HELI adopts Wuxi CA6110 diesel engine. USA import Cummins QSB4.5 diesel engine which conforms to the requirements of EU stage III, U.S EPA tier 3.
● HELI specially used home-made gearbox which is arranged as two at the front and two at the back. With the electro hydraulic reversing control, the operation is laborsaving.
● HELI adopts the Meritor heavy-duty drive axle With inlaid disc braking which has reliable performance and stable quality, also and cost performances
● The heat radiation system is safe and reliable, and the power of it is great.
● The operation of service brake and parking brake is stable.
| Model | unit | CPCD120-WX-06II | CPCD120-CU-06II | CPCD140-CU3 | CPCD150-CU3 | CPCD160-CU3 |
| Rated Load Capacity | kg | 12000 | 12000 | 14000 | 15000 | 16000 |
| Load Center | mm | 600 | 600 | 900 | 900 | 900 |
| Power type | Diesel | Diesel | Diesel | Diesel | Diesel | |
| Driving style | Seated | Seated | Seated | Seated | Seated | |
| Standard lift height | mm | 3000 | 3000 | 3000 | 3000 | 3000 |
| Fork size(Length/width/thickness) | mm | 1370/175/80 | 1370/175/80 | 1820/250/90 | 1820/250/90 | 1820/250/90 |
| Overall length(with forks) | mm | 4400(5770) | 4400(5770) | 7410 | 7410 | 7410 |
| Overall width | mm | 2350 | 2350 | 2560 | 2560 | 2560 |
| Overall Height(Mast) | mm | 3170 | 3170 | 3340 | 3340 | 3340 |
