● Compact layout, provides good appearance. ● Low exhausting ,high working efficiency. ● Steering system adopt chain wheel structure, has high efficiency ,prolong the using life.8-25t four pivot sit down AC type, steering system adopt hydraulic power ,reduce operating intension. ● Configuration inching switch , the driver achieves hanging pin by himself. ● Battery can be side-pulled out from the truck. improve working efficiency.
| Model | unit | QYD15S-E1 | QYD20S-E1 | QYD30S-E1 | QYD40S-E1 | QYD50S-E1 | QYD60S-E1 |
| Driving mode | Seated | Seated | Seated | Seated | Seated | Seated | |
| Steering mode | Mechanical steering | Mechanical steering | Mechanical steering | Mechanical steering | Mechanical steering | Mechanical steering | |
| Travel speed, with/without load | km/h | 9 /12 | 9 /12 | 9 /12 | 9 /12 | 10 /15 | 10 /15 |
| Grade ability with load | %*m | 10*20 | 6*20 | 6*20 | 6*20 | 6*20 | 6*20 |
| Turning radius | mm | 1550 | 1550 | 1550 | 1850 | 1800 | 1800 |
| Battery(Standard) | V/Ah | 24/280 | 24/350 | 24/280 | 48/280 | 48/380 | 48/420 |
| Total weight(with battery) | kg | 750 | 750 | 810 | 1090 | 1650 | 1730 |
