● Integrated hydraulic pump station. ● 100Ah Maintenance free storage battery. ● Easy-operating.
| Model | Unit | CBS10 | CBS15 | CBS10 | CBS15 |
| Configuration number | Z160 | Z160 | K160 | K160 | |
| Type | Fork over | Fork over | Adjustable Straddle | Adjustable Straddle | |
| Mast type | Standard 2-Stage | Standard 2-Stage | Standard 2-Stage | Standard 2-Stage | |
| Operator type | Walkie | Walkie | Walkie | Walkie | |
| Load Capacity | kg | 1000 | 1500 | 1000 | 1500 |
| Standard lift height | mm | 1600/2000/2500/3000/3500 | 1600/2000/2500/3000/3500 | 1600/2000/2500/3000/3500 | 1600/2000/2500/3000/3500 |
| Load Center | mm | 500 | 500 | 400 | 400 |
| Fork size(length/width/thickness) | mm | 1150(1000)/160/60 | 1150(1000)/160/60 | 915(1070)/100/30 | 915(1070)/100/30 |
| Overall length | mm | 1580 | 1580 | 1484 | 1484 |
| Overall width | mm | 730 | 730 | 1160/1300/1440 | 1160/1300/1440 |
| Motor | KW | 1.6 | 1.6 | 1.6 | 1.6 |
| Battery (voltage/capacity) | V/Ah | 12/100 | 12/100 | 12/100 | 12/100 |
