● The diesel engines including 6 cylinder and turbocharger of VOLVO company (Sweden) is used. With great power and torque, it is suitable for all-weather operation. High in performance and low in oil consumption .
● The products of DANA Company or ZF Company are used. The gearbox adopts the control parts that integrate various kinds of control programs and can easily realize various control operation. It is furnished with fault diagnostic apparatus, greatly facilitates the maintenance.
● The heavy-duty drive axle of KESSLET Company, Germany is used. The axle with large capacity and brake torque, is safe and reliable. The multiple-piece wet type is fully enclosed, maintenance free, safe and reliable and is equipped with caliper disc parking brake.
● ELME spreader has a single-type main frame which enhances visibility when high stacking, and has the mechanical and electrical double security protection.
●The products of PARKER Company, USA is used, which, both efficient and reliable, is operated with single handle and piloted control. It can relieve the fatigue of the drivers because of simple operation and energy saving.
● The hydraulic oil circuit equipped with forced cooling system ,can meet the requirements of high intensity work.
● The control parts adopts modular and highly integrated DVEC (double central distribution box) design. With advanced programmable 3D matrix technology, it is easy to alter. The connectors made by AMP and DELPHI have good dustproof and splash-proof functions.
● The drive seat in the drive cab adopts full suspension and vibration proof structure and can be adjusted in all directions. Each operation pedals and handle position are designed according to the principle of human engineering and can greatly reduce the labor intensity. High-mounted cabin provided excellent all-round visibility. Air conditioner is standard. And the sliding type bonnet facilitates the maintenance and repair.
Model | CPCD250EC7-VDG(7 layers) | CPCD250EC8-VDG(8 layers) | |
Load capacity | kg | 9000 | 9000 |
Load center | mm | 1220 | 1220 |
Lifting height | mm | 16500 | 19000 |
Mast angle(front/back) | deg | 3/3 | 3/3 |
Overall width | mm | 4150 | 4150 |
Wheel base | mm | 4250 | 4250 |
Min. turning radius | mm | 5918 | 5918 |
Max. lifting speed(with/without load) | mm/s | 590/600 | 590/600 |
Max. travel speed(with/without load) | km/h | 28/29 | 28/29 |
